Spherical Bearings (Steel Cage CC & Brass Cage MB Design Spherical Bearings)
HBL Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts. Main application is Industrial machinery, Construction Machinery , Hoist, Cranes, Loaders & Crusher Plants. HBL Manufactures Spherical Bearings as per ISO 15:2017 , ISO 5753-1:2009 & GOST 520-2011 , GOST 24696-81.
Key Features of HBL Spherical Bearings steel cage CC design :
- Accommodate misalignment
- High Load carrying capacity
- Relubrication Features
- Increased wear resistance
- Self Aligning upto 5 degrees
| HBL's Production Range of Spherical Roller Bearings in CC & MB Design | ||||||
|---|---|---|---|---|---|---|
| 22205 | 22307 | 21304 | 23020 | 24022 | ||
| 22206 | 22208 | 21305 | 23022 | 24024 | ||
| 22207 | 22309 | 21306 | 23024 | 24026 | ||
| 22208 | 22310 | 21307 | 23026 | 24028 | ||
| 22209 | 22311 | 21308 | 23028 | 24030 | ||
| 22210 | 22312 | 21309 | 23030 | 24032 | ||
| 22211 | 22313 | 21310 | 23022 | 24034 | ||
| 22213 | 22314 | 21311 | 23024 | 24036 | ||
| 22214 | 22315 | 21312 | 23026 | 24038 | ||
| 22215 | 22316 | 21313 | 23028 | 24040 | ||
| 22216 | 22317 | 21314 | 23030 | 24120 | ||
| 22218 | 22318 | 21315 | 23120 | 24122 | ||
| 22219 | 22319 | 21316 | 23122 | 24124 | ||
| 22220 | 22320 | 21317 | 23124 | 24126 | ||
| 22222 | 22322 | 21318 | 23126 | 24128 | ||
| 22224 | 22324 | 21319 | 23128 | 24130 | ||
| 22226 | 22326 | 21320 | 23215 | 24132 | ||
| 22228 | 22328 | 21322 | 23218 | 24134 | ||
| All Mentioned Sizes available in CC Steel Cage & MB Brass Cage Design | ||||||
| HBL Spherical roller bearing comes with relubrication features W 33 | ||||||
